Description
Part Number: 2051TG1A2B21AB4I5M5
Model: 2051T - In-line Pressure Transmitter
Pressure type: G - Gage
Pressure range: 1 - -14.7 to 30 psi (?1,0 to 2,1 bar)
Transmitter output: A¹ - 4?20 mA with Digital Signal Based on HART Protocol
Process connection style: 2B - 1/2?14 NPT female
Isolating diaphragm: 2² - 316L SST; [Process connection wetted parts material] 316L SST
Sensor fill fluid: 1 - Silicone
Housing material: A - Aluminum; [Conduit entry size] 1/2?14 NPT
Mounting brackets: B4 - Coplanar flange bracket for 2-in. pipe or panel mounting, all SST
Product certifications: I5 - USA Intrinsically Safe, Division 2
Display and interface options: M5 - LCD display
Model: 2051T - In-line Pressure Transmitter
Pressure type: G - Gage
Pressure range: 1 - -14.7 to 30 psi (?1,0 to 2,1 bar)
Transmitter output: A¹ - 4?20 mA with Digital Signal Based on HART Protocol
Process connection style: 2B - 1/2?14 NPT female
Isolating diaphragm: 2² - 316L SST; [Process connection wetted parts material] 316L SST
Sensor fill fluid: 1 - Silicone
Housing material: A - Aluminum; [Conduit entry size] 1/2?14 NPT
Mounting brackets: B4 - Coplanar flange bracket for 2-in. pipe or panel mounting, all SST
Product certifications: I5 - USA Intrinsically Safe, Division 2
Display and interface options: M5 - LCD display
