Description
Part Number: 7MF0300-1WE01-5AM2-Z A00+H02+C12+E01+E09+E09
Model: SITRANS P320 Pressure Transmitter
Manufacturer: Siemens
Condition: New & Original in Factory Packing
Factory Warranty: 12 Months
SITRANS P320 Pressure transmitter Gauge pressure HART (4...20 mA) Measuring cell filling: Silicone oil Maximum measuring span: 63 bar (914 psi) Male thread G1/2A (DIN EN 837-1) Diaphragm: Stainless steel 316L/1.4404, measuring cell: Stainless steel 316L/1.4404; Sensor Differential pressure: process flange: Stainless steel 316/1.4408 Die-cast aluminum housing Dual chamber device no Ex 2 x M20 x 1.5 With display (lid with glass window) Cable gland attached, plastic Labeling type plate German - bar Quality inspection certificate - 5 point factory calibration (IEC 60770-2) General approval without Ex approval: World (CE, RCM) except: EAC, FM, CSA, KCC Measuring range setting: Lower range value (max. 5 characters). Upper range value (max. 5 characters). Unit (mbar. bar. kPa. MPa. psi. ...) Example: -0.5 ... 10.5 psi
Model: SITRANS P320 Pressure Transmitter
Manufacturer: Siemens
Condition: New & Original in Factory Packing
Factory Warranty: 12 Months
SITRANS P320 Pressure transmitter Gauge pressure HART (4...20 mA) Measuring cell filling: Silicone oil Maximum measuring span: 63 bar (914 psi) Male thread G1/2A (DIN EN 837-1) Diaphragm: Stainless steel 316L/1.4404, measuring cell: Stainless steel 316L/1.4404; Sensor Differential pressure: process flange: Stainless steel 316/1.4408 Die-cast aluminum housing Dual chamber device no Ex 2 x M20 x 1.5 With display (lid with glass window) Cable gland attached, plastic Labeling type plate German - bar Quality inspection certificate - 5 point factory calibration (IEC 60770-2) General approval without Ex approval: World (CE, RCM) except: EAC, FM, CSA, KCC Measuring range setting: Lower range value (max. 5 characters). Upper range value (max. 5 characters). Unit (mbar. bar. kPa. MPa. psi. ...) Example: -0.5 ... 10.5 psi
