Yokogawa EJX110A-ELS4G-917DB/KU22/M11/T12 EJX110A Differential Pressure Transmitter

Description

Manufacturer: Yokogawa
Yokogawa Pressure Transmitter
Product Number: EJX110A-ELS4G-917DB/KU22/M11/T12

Model and Suffix Codes
Model: EJX110A -  Gauge Pressure Transmitter
Output signal: -E - 4 to 20 mA DC with digital communication (HART 5 protocol)
Measurement span (capsule): L - 0.1 to 10 kPa (0.4 to 40 inH2O) (For Wetted parts material code M, H, T, A,D, B and W)

Wetted parts material?: S -
Cover flange and process connector: ASTM CF-8M?
Capsule: Hastelloy C-276? (Diaphragm); F316L SST, 316L SST (Others)
Capsule gasket: Teflon-coated 316L SST
Vent/Drain plug: 316 SST

Process connections: 4 - with 1/2 NPT female process connector
Bolts and nuts material: G - 316L SST
Installation: -9* - Horizontal piping and left side high pressure
Amplifier housing: 1 - Cast aluminum alloy
Electrical connection: 7 - M20 female, two electrical connections and a blind plug4
Integral indicator: D - Digital indicator5
Mounting bracket: B - 304 SST 2-inch pipe mounting, flat type (for horizontal piping)

Optional Codes:
/KU22
Combined KF22, KS21 and ATEX Intrinsically safe Ex ic6,7
    [ATEX Instrisically safe Ex ic]
           Applicable Standard: EN 60079-0:2012, EN 60079-11:2012
          II 3G Ex ic IIC T4 Gc, Amb. Temp.: -30 to 60?C (-22 to 140?F)8
          Ui=30 V, Ci=27.6 nF, Li=0 H

/M11
Material certificate9 : Cover flange, Process connector10

/T12
Pressure test/Leak test certificate11
       Test Pressure: 16 MPa(2300 psi)12
              Nitrogen(N2) Gas Retention time: one minute


NOTE:
The " * " marks indicate the most typical selection for each specification.

1. Users must consider the characteristics of selected wetted parts material and the influence of process fluids. The use of inappropriate materials can result in the leakage of corrosive process fluids and cause injury to personnel and/or damage to plant facilities. It is also possible that the diaphragm itself can be damaged and that material from the broken diaphragm and the fill fluid can contaminate the users process fluids.  Be very careful with highly corrosive process fluids such as hydrochloric acid, sulfuric acid, hydrogen sulfide, sodium hypochlorite, and high-temperature steam (150?C [302?F] or above). Contact Yokogawa for detailed information of the wetted parts material.
2. Cast version of 316 SST. Equivalent to SCS14A.
3. Hastelloy C-276 or ASTM N10276.
4. Material of a blind plug is aluminum alloy or 304 SST.
5. Not applicable for output signal code G.
6. Applicable for Electrical connection code 2, 4, 7, 9, C and D.
7. Not applicable for option code /AL.
8. Lower limit of ambient temperature is 15?C (5?F) when /HE is specified.
9. Material traceability certification, per EN 10204 3.1B.
10. Applicable for process connections codes 1, 2, 3, and 4.
11. Applicable for wetted parts material code S; process connection code 0 and 5; and installation code 8 and 9. Not applicable for option code U1, N2, N3 and M11. No PTFE is used for wetted parts.
12. Applicable for capsule code F and L. Also applicable for capsule M, H and V when combined with Wetted Parts Material code H, M, T, A, D, B and W.
